Bandit75
MODEL 200 UC REPLACEMENT PARTS
Anvil Bolt Torque: 75 ft.-lbs. (102 Nm)
# Part Number Description
1
980-0123-09
Anvil Only (1/2”) - 4 Side
(Start 10/16)
980-0133-52
Anvil Only (3/8”) - 4 Side
(Pre 10/16)
2
900-4903-54 5/16”-18NC x 1/2” Set Screw
3
900-4906-39
5/16”-18NC x 1 1/2” Hex Head
Bolt
4
900-4910-73 5/16”-18NC Hex Nut
5
900-4902-58 Anvil Washer
6
900-4906-86 1/2” Lock Washer
7
900-4906-72
1/2”-13NC x 1 1/2” Hex Head
Bolt
# Part Number Description
8
900-4902-73
Anvil Eye Bolt -
1/2”-13NC x 5 1/2”
9
900-4906-74 1/2”-13NC x 2” Hex Head Bolt
10
900-4906-82 1/2”-13NC Hex Nut
11
900-4906-90 1/2” USS Flat Washer
12
914-300131 Anvil Gauge
13
980-0508-97
Anvil Hardware Only
(Includes 2 - 12)
14
980-0507-77
Anvil & Hardware Kit
(Includes 1 - 12)
ANVIL & HARDWARE
2
1
3
10
10
11
11
11
5
12
5
8
8
6
6
7
6
11
5
9
9
10
10
11
4
To Next Page
