Banner D10 Expert Series Quick Start Guide

D10 Expert™ Discrete Output with Bargraph Display
Dimensions
10.0 mm
(0.39")
35.1 mm
(1.38")
10.0 mm
(0.39")
15.2 mm
(0.60")
2x C'sink
ø8.0 mm (0.31")
3.2 mm (0.13") deep
ø4.4 mm (0.18") thru
max. torque 10 in./lbs.
2x 3.5 mm
(0.14")
5.0 mm
(0.20")
8.6 mm
(0.34")
25.4 mm
(1.00")
16.0 mm
(0.63")
2 x ø3.3 mm (0.13") max. torque 6 in./lbs.
2x ø3.2 mm (0.13") max. torque 6 in./lbs.
2.5 mm (0.10")
5.0 mm (0.20")
M3 Hardware included:
Lock Washer (2)
Flat Washer (2)
Screws (2)
Hex Nuts (2)
Bracket Dimensions (Bracket included with Standard Sensor Models)
61.3 mm
(2.42")
68.1 mm
(2.68")
10.5 ± 0.2 mm (typ.)
(0.41")
14.5 mm
(0.57")
Mounting Bracket
(included with some models)
35.9 mm
(1.41")
7.6 mm
0.30"
9.8 mm
(0.39")
Plastic Fiber
Emitter Port
Plastic Fiber
Receiver Port
Slides Up to
Release Fibers
61.3 mm
(2.42")
68.1 mm
(2.68")
Plastic Fiber
Emitter Port
Plastic Fiber
Receiver Port
10.5 ± 0.2 mm (typ.)
(0.41")
Mounting Bracket
(included)
Slides Up to
Release Fibers
35.9 mm
(1.41")
7.6 mm
0.30"
9.8 mm
(0.39")
Installing Fibers
