Appendix C. – Technical Specifications
General Part
Frequency Range GMRS(462/467MHz)
Working temperature -10℃ to +40℃
Operation Voltage DC 3.7 V ±10%
Operation Mode Simplex
Dimensions 114mm×61mm×30mm (without Antenna)
Weight 130g (Battery pack included)
Antenna Impedance 50ohm
Transmitter Part
RF Output Power ≤2W (1-7&15-22&23-38Channels) /≤0.5W(8-14Channels)
FM Modulation 11K0F3E@12.5KHz
Adjacent Channel Power 60dB @ 12.5KHz
Transmission current ≤1000mA
Receiver Part
Receive Sensitivity 0.25μV (12dB SINAD)
Adjacent Channel Selectivity ≥55dB@12.5KHz
Inter Modulation and Rejection ≥55dB@12.5KHz
Conducted Spurious Emission ≤-57dB@12.5KHz
Rated Audio Power Output 0.75W @8 ohms
Receive current ≤380mA
Rated Audio Distortion ≤5%
NOTE: All specifications may be modified without prior notice or liability.
