Assembly instructions (continued)
STEP 5 ONLY IF JOINING ADJACENT BBQS:
If you are joining two carts together, e.g. a 2B and 4B to make a 6B, then first assemble each unit
onto its respective cart as above. Adjust the cart heights to match each other, and join the adjacent
carts and fireboxes as detailed below.
(a) Bolt the adjacent carts together
WHAT YOU NEED
4x M6*15mm screws
4x M6 hex nuts
Join the two carts using two M6*15mm screws, and hex nuts as shown below:
Follow the instructions that came with the cart to properly level the carts and adjust the castors if
necessary so they are all in contact with the ground once the carts are level.
