Barco Coronis Fusion 10MP - Rear View

10 Coronis Fusion 10MP
Rear view
USB downstream connector USB upstream connector
Ethernet connector (see note
below)
DVI 1 video input
DisplayPort 1 video input Connector compartment
cover
Neck cover Display stand cover
DisplayPort 2 video input DVI 2 video input
+5 VDC, 0.5 A power output +24 VDC power input
The Ethernet connection is used for maintenance purposes and
is not supported for user application.
6 87
1 2 3 4 5
9 10 11 12
1 2
3 4
5 6
7 8
9
10
11 12
