35.65
905.5
23.40
594.4
BRACKET POSITIONS SHOWN
ARE FOR TS325
ROTATE BRACKETS
180 DEGREES FOR TS525
GROUNDING
SCREW
GROUNDING
SCREW
34.00
863.6
21.75
552.5
TRIM NOT SHOWN
(USE THESE DIMENSIONS FOR CUTOUT)
3.96
100.5
3.63
92.1
34.00
863.6
4X
2.33
59.2
24.25
616.0
A
B
KNOCK OUT FOR ELECTRICAL
JUNCTION BOX (SEE NOTES)
(2 PLACES)
KNOCK OUT FOR CABLE
ACCESS (SEE NOTES)
(2 PLACES)
0.56
1.13
1.10
2.20
0.16
3.43
3.75
3.93
0.14 4X
DETAIL A
SCALE 1 : 3
1.39
2.49
DETAIL B
SCALE 1 : 3
D
C
B
A
A
B
C
D
SIZE
B
8
7
6
5
4
3
2
1
1
2
3
4
5
6
7
8
TECH-000104
THINSTALL IN-WALL BOX - LARGE
6436 CITY WEST PKWY
EDEN PRAIRIE MN, 55344
PHONE: 866-977-3901
FAX: 877-894-6918
SHEET 1 OF 2
THE INFORMATION AND DESIGNS CONTAINED IN
THIS DRAWING ARE CONFIDENTIAL AND THE
PROPRIETARY PROPERTY OF MILESTONE AV
TECHNOLOGIES NEITHER THIS DESIGN NOR ANY
INFORMATION CONTAINED IN THIS DRAWING
MAY BE REPRODUCED OR DISCLOSED TO OTHERS
WITHOUT THE EXPRESS WRITTEN CONSENT OF
MILESTONE AV TECHNOLOGIES.
DRAWN BY
CAD GENERATED DRAWING,
DO NOT MANUALLY UPDATE.
LRP
LRP
8/20/2012
8/20/2012
ENG APPROVAL
MFG APPROVAL
QA APPROVAL
SCALE
1:8
TECH-000104
STATUS:
JS 10/21/2015 - RELEASED ON ECO: 500012677
03
DESCRIPTION
REV.
DWG. NO.
MODEL NO.
TA500
NOTES:
ELECTRICAL KNOCK OUTS:
1.
SINGLE GANG RACO 590.
•
STEEL CITY CY 1/2, OR
SIMILAR STYLE ELECTRICAL
BOX.
1" AND 2" TRADE PIPE CONDUIT.
•
PRODUCT WORKS WITH TS525 AND TS325.
