Barco MD-4221 - Specifications

40
Specifications
Model MD-4221
Type TFT-LCD
Screen Size 42 inch
Maximum Resolution 1920 X 1080 @ 60Hz
Pixel pitch 0.4845(H) mm X 0.4845(V) mm
Display Colors 16.7M
Contrast Ratio 1300:1
Viewing Angle 89° / 89° / 89° / 89°
Response Time 10msec(Rising+Falling)
LCD Panel
Luminance 500cd/m²
Horizontal Frequency 30KHz~93KHz
Synchronization
Vertical Frequency 50Hz~85Hz
Power Maximum 260W
Consumption Standby Mode Typical 17W
Width side INPUT, -, +, ▼, ▲, PIP, MENU, POWER
Control key
Front side IR Receiver
Input Signal
Video
1XDVI, 1XD-SUB, 1XBNC (CVBS) 2XBNC
(SVHS Y/C), 1XBNC (SDI), 5XBNC
(Component Y/G, Pb/B, Pr/R, H/CS, VS
Input)
Out Signal
Video 1XDVI, 1XBNC (SDI)
Input power
AC 100-240V~, 50-60Hz 3A MAX
Dimension
Size and Weight 1023.5x615.5x105(mm)/ 29Kg
