Barco RFD-251 - Technical Specifications Overview; Electro-Optical Specifications; Connections and Power; Controls, Indicators, and General Data

www.barcodefense.com
K5906062 rev.01.00 0706
Technical specifications are subject to change without prior notice
TEMPERATURE operating
storage
HUMIDITY operating
VIBRATION operating
SHOCK operating
ALTITUDE operating
storage
EMI/EMC
RAPID DECOMPRESSION
DRIP PROOF
(installed in console)
MTBF
SAFETY
FUNGUS
-25°C/-13°F - 55°C/131°F
(MIL-STD-810E)
-40°C/-40°F - +70°C/+158°F
(MIL-STD-810E)
95% @ 40°C (MIL-STD-810E)
MIL-STD-167-1, MIL-E-5400T, 2g
30g - 12,5ms half sine
(MIL-STD-810C)
25,000 ft (MIL-STD-810E)
40,000 ft (MIL-STD-810E)
MIL-STD-461D: Ground,
army aircraft, air force
N/A
On the front
80,000 hrs (G
B
@ 20°C)
(MIL-HDBK-217F)
Meets IEC 60950
MIL-STD-810E
RFD-251
Barco
Pres. Kennedypark 35 - B-8500 Kortrijk, Belgium
Phone: +32 56 233 412 - Fax: +32 56 233 462
E-mail: sales.defense@barco.com
-25°C/-13°F - 55°C/131°F
(MIL-STD-810E)
-40°C/-40°F - +70°C/+158°F
(MIL-STD-810E)
95% @ 40°C (MIL-STD-810E)
MIL-STD-167-1, MIL-E-5400T, 2g
60g - 33ms full sine
(MIL-STD-810C,
MIL-STD-901D Grade A)
25,000 ft (MIL-STD-810E)
40,000 ft (MIL-STD-810E)
MIL-STD-461D: Surface ship,
submarine
N/A
On the front
23,000 hrs (N
S
@ 25°C)
(MIL-HDBK-217F)
Meets IEC 60950
MIL-STD-810E
RFD-251 S
-25°C/-13°F - 55°C/131°F
(MIL-STD-810E)
-40°C/-40°F - +70°C/+158°F
(MIL-STD-810E)
95% @ 40°C (MIL-STD-810E)
MIL-STD-167-1, MIL-E-5400T, 5g
30g - 12,5ms half sine
(MIL-STD-810C)
25,000 ft (MIL-STD-810E)
40,000 ft (MIL-STD-810E)
MIL-STD-461D: Aircaft, navy
35,000ft in max 15s (MIL-STD-810E)
On the front
17,000 hrs (AIC @ 25°C)
(MIL-HDBK-217F)
Meets IEC 60950
MIL-STD-810E
RFD-251 AEnvironment
ELECTRO OPTICAL
Panel Type Front bonded analog active matrix LCD
(Silicone TFT)
Panel Size 20.1” (51 cm) diagonal
Pixel Dimensions 0.312 x 0.312 (RGB vertical stripe)
Resolution SXGA – 1280 x 1024 pixels
Image Dimensions 399 x 319 mm (15.7 x 12.6”)
Panel Specifications 16M colors, 256 gray scales
Brightness 210 cd/m
2
(61.3 fL) typical
Contrast Ratio 300:1 typ. in Dark Environment
Color Temperature 6800°K
White Uniformity 30% non-uniform
Viewing Angle Horizontal and Vertical: ± 85° (CR > 10)
Response time t
r
= 10 ms, t
f
= 10 ms (Black to white)
CONNECTIONS
Signal Inputs Coax BNC connectors for RGB,
HS/CS, VS (VGA to SXGA)
RS-232 Serial Port 9 pin sub-D connector
Power MIL-C-38999 series I
(28V
DC
+ 115/230 V
AC
)
HE 308 type connector
Optional for 115/230 ITT-Canon
(MIL-C-5015)
CONTROLS & INDICATORS
Bezel Controls SELECT/STAND BY/UP/DOWN
Bezel Indicators Green ‘Power’ LED, Red ‘Overtemp’ &
‘Fault’ LED, Yellow ‘Calibrated’ LED
Remote Control RS-232 port
POWER
Power Supply 28 V
DC
; 115/220 V
AC
; or
115 V
AC
, 44-440Hz
Design Requirements MIL-STD-704
Power Consumption Nominal: 70W, Cold Start: 130W
GENERAL DATA
Mounting 19” Rack Mount
Weight < 13.4 kg (30 lbs)
Cooling Natural Convection, No Fans
MTTR < 30 minutes
ENVIRONMENTAL OPTIONS
RFD-251 -25°C / -40°F cold start
RFD-251 A 6.6 g RMS Random Vibration,
Endurance Level
RFD-251 S Shock: 60 g - 33ms full sine
(MIL-STD-810C and MIL-STD-901D Grade A)
For other custom options, please contact Barco.
Technical specifications
Barco Federal Systems Corporation
3059 Premiere Parkway, Suite 100
Duluth, Georgia, 30097-4905, USA
Phone: +1 678 475 8000 - Fax: +1 678 475 8100
Email: sales.defense@barcofederal.com
BarcoView-TEXEN
7 Rue Roger Camboulives
BP 1226 - F-31037 Toulouse, France
Phone: +33 5 34 63 71 74 - Fax: +33 5 34 63 70 20
Environmental specifications
