Bard MC4002-BC User Manual

Manual 2100-614K
Page 60 of 61
Parts List
Dwg.
No.
Part No. Description MC4002 MC4002-A MC4002-AC MC4002-B MC4002-BC AB3000-A AB3000-B
CB5000
Series
1 127-343-4 Control Box X X X X X
2 8612-043 Controller Board X X X X X
3 8612-049 Alarm Board A* X X X
3 8612-050 Alarm Board B* X X X
4 8612-022 Alarm Display X X X X X X
5 113-430-4 Support Bracket X X X X X
6 152-625-4 Control Box Door X X X X X
7 8611-099 LTF Fitting X X X X X
8 5400-002 Hinge X X X X X
9 8612-023A Sensor X X X X X
10 7961-731 Label/Keypad X X X X X
11 8611-006 Ground Lug 2 2 2 2 2
12 8612-047
Communication
Board
X X X
13 8607-030 Terminal Block X X X X X
14 113-588 Fuse Bracket X X X X X
15 8614-056 Fuse Holder X X
X X X
16 1171-023
1/4 Turn
Receptacle
X X X X X
17 1171-022
1/4 Turn
Fastener
X X X X X
18 8614-057 Fuse X X X X X
NS 8612-039
Communication
Cable
X X X
NS 8612-051
Alarm Board
Cable
X X X X X X
* 8612-051 alarm board cable included with these alarm boards
NS – Not Shown
