Bard Site-Rite IV - 10 Technical Specifications; 10.1 Site-Rite IV Scanner Specifications; 10.2 Site-Rite IV Probe Specifications; 10.3 Site-Rite IV Power Source Specifications

29
English
Site~Rite
*
IV Ultrasound System Operator’s Manual
29
Chapter 10: Warranty and Service
10 Technical Specifications
10.1 Site~Rite
*
IV Scanner Specifications
Dimensions: 10” x 6.75” x 8” (540 in
3
)
Weight: 6.2 lbs. (2.8 kg)
Power Sources: AC adapter, DC Battery Pack
Power Consumption: 14.4 VDC @ 1.5 A
Monitor Size: 3.8”
Y2K Compliant: yes
IEC 60601- 1: Class I, Type BF Applied Part, Continuous Operation, Internally Powered Equiptment,
Not Category AP or APG Equiptment, Not protected against ingress of water.
Probes: 7.5 MHz, 9.0 MHz
Fuse: 5 A 125 V MicroTM Fuse (Part Number: 273 005 Manufactured by Littelfuse, Inc.)
10.2 Site~Rite
*
IV Probe Specifications
9.0 MHz Probe
Ultrasonic Frequency: 9.0 MHz
Sector Angle: 26°
Crystal to Cap Standoff Distance: 4.0 cm
Scan Depth from Probe Cap: 2.0/4.0 cm
Frame Rate: 24 frames/second
Line Density: 129 lines/frame
Focal Length: 0.5 cm from cap
Focal Zone: 0.0 to 1.5 cm from cap
10.3 Site~Rite
*
IV Power Source Specifications
DC Battery Pack Specifications
Dimensions: 5.0” (12.7 cm) W x 4.25” (10.8 cm) H x 1.75” (4.5 cm) L
Weight: 1.9 lbs. (0.86 kg)
Battery Type: Nickel-Metal Hydride
Output Voltage: 14.4 VDC
Duration of Site~Rite IV Operation when fully charged: 2 hours
AC Adapter Specifications
Dimensions: 5.0” (12.7 cm) W x 4.25” (10.8 cm) H x 1.75” (4.5 cm) L
Weight: 1.4 lbs. (0.64 kg)
Input Voltage: 100 - 240 VAC, 50 - 60 Hz, 1.2 amp
Output Voltage: 15 VDC
Charge~Rite Battery Charger Specifications
Dimensions: 8.0” (20.3 cm) W x 4.7” (11.9 cm) H x 6.4” (16.3 cm) L
Weight: 3.2 lbs. (1.5 kg)
Approximate Time for 85% Battery Recharge: 2.5 hours
Power Source: 90 - 264 VAC, 47 - 63 Hz, 1.0 amp
Site~Rite Mini Battergy Charger Specification
Dimensions: 2.2” (55mm) W x 1.7” (43mm) H x 3.2” (80mm) L
Weight: 0.450 Lbs. (0.204 kg)
Approximate Time for 85% Battery Recharge: 2.5 hours
Power Source: 100 - 250 VAC, 50 - 60 Hz, 1.0 amp
IEC 60601- 1: Class II, Continuous Operation, Not Category AP or APG Equiptment, Not protected
against ingress of water.
US Part Number: NX1210MU6DBNN
EU Part Number: NX1210ME6DBNN
7.5 MHz Probe
Ultrasonic Frequency: 7.5 MHz
Sector Angle: 26°
Crystal to Cap Standoff Distance: 4.0 cm
Scan Depth from Probe Cap: 2.0/4.0 cm
Frame Rate: 24 frames/second
Line Density: 129 lines/frame
Focal Length: 2.0 cm from cap
Focal Zone: 1.0 to 4.0 cm from cap
