Bard W3RV2-R User Manual

Manual 2100-615A
Page 23 of 24
TABLE 6
ELECTRIC HEAT
TABLE 4
RECOMMENDED AIRFLOW
TABLE 5
MAXIMUM ESP OF OPERATION
ELECTRIC HEAT ONLY
Values shown are for units equipped with standard 1-inch
throwaway filter or 1-inch washable filter.
Derate ESP by .15 for 2-inch pleated filters.
Model
Rated
CFM*
Rated
ESP*
Recommended
Airflow Range
W3R/LV 1100 .15 1100 - 550
W5R/LV 1700 .20 1700 - 850
W6R/LV 1700 .20 1700 - 850
Model
W3 W5, W6
FRONT FRONT
High High
-A0Z
-A05
-A10
.50
.50
.50
.50
.50
.50
-B0Z
-B06
-B09
.50
.50
.50
.50
.50
.50
-C0Z
-C09
-C12
.50
.50
.45
.50
.50
.50
Models 240V-1 208V-1 240V-3 208V-3 460V-3
KW Amps BTUH Amps BTUH Amps BTUH Amps BTUH Amps BTUH
4 16.7 13650 14.4 10240
5 20.8 17065 18.1 12800
6 14.4 20500 12.5 15360 7.2 20500
8 33.3 27300 28.8 20475
9 21.7 30600 18.7 23030 10.8 30700
10 41.6 34130 36.2 25600
12 14.4 40950
15 62.5 51250 54.0 38400 36.2 51200 31.2 38400 18.0 51200
18 43.3 61430 37.5 46100
20 83.2 68260 72.1 51200
* Rated CFM and ESP on high speed tap.
