FIGURE 2
All dimensions are in inches. Dimensional drawings are not to scale.
W*RV
RIGHT
UNIT
W*LV
LEFT
UNIT
Dimensions of Basic Unit for Architectural and Installation Requirements (Nominal)
MODEL
WIDTH
(W)
DEPTH
(D)
HEIGHT
(H)
SUPPLY RETURN
A B C B E F G I J K L M N O P Q R S1 S2 T
W3RV2
W3LV2
38.200 17.125 70.563 7.88
27.88 13.88 27.88 40.00 10.88 25.75 17.93 26.38 28.75 29.25 27.00
2.75
39.19 22.75
9.14 4.19
12.00 12.00
5.00
W5RV2
W5LV2
42.075 22.432 84.875 9.88
29.88 15.88 29.88 43.88 13.56 31.66 30.00 32.31 26.94 34.69 32.43
3.37
42.88 23.88
10.00 1.44
16.00 16.00
1.88
W6RV2
W6LV2
42.075 22.432 94.875 9.88
29.88 15.88 29.88 43.88 13.56 41.66 30.00 42.31 36.94 44.69 42.43
3.37
42.88 33.88
10.00 1.44
16.00 21.00
1.88
