Manual 2110-1418G
Page 12 of 16
NS – Not Shown
– Optional
FUNCTIONAL COMPONENTS – RIGHT & LEFT HAND
W6RV2-S
W6RV2-T
W6LV2-S
W6LV2-T
Drawing No. Part No. Description
1
1
8000-358
8000-359
Compressor
Compressor
X
X
X
X
2
2
S900-340-001
S900-341-001
Blower Assembly
Blower Assembly
X
X
X
X
3 8200-004 Fan Motor Mount X X X X
4 5151-060 Fan Blade X X X X
5
5
S8106-061-0132
S8106-058-0133
1/2 HP ECM Motor with Programmed Control
1/2 HP ECM Motor with Programmed Control
X
X
X
X
6 5051-088BX Condenser Coil X X X X
7 5651-213 Cooling TXV X X X X
8 5060-082BX Evaporator Coil X X X X
9
9
9
7004-016
7003-030
7004-027
Air Filter 1" Throw-Away
Air Filter 1" Washable
Air Filter 2" Pleated
X
X
X
X
X
X
X
X
X
X
X
X
10 1171-022 1/4 Turn Fastener X X X X
11 1171-024 1/4 Turn Retainer X X X X
12 1171-023 1/4 Turn Receptacle X X X X
13 8406-142 High Pressure Switch - Red Leads X X X X
14 5650-049 Solenoid Valve X X X X
15 5202-018 Accumulator X X X X
16
5203-007 Receiver X X X X
17 800-0395 Cooling Distributor Assembly X X X X
18 8406-135 Low Pressure Switch - Blue Leads X X X X
NS 5201-002 Filter Drier X X X X
NS
NS
8605-017
8605-018
Crankcase Heater
Crankcase Heate
X
X
X
X
NS 8408-039 Discharge Line Thermostat X X X X
NS 8406-128 Pressure Transducer X X X X
NS 5451-024 Grommet Retainer 2 2 2 2
This table references exploded views on pages 10 & 11
