9. CLEARANCES
Minimum clearances, as specified in Table 2, must be
maintained from adjacent structures to provide
adequate fire protection, adequate combustion air, and
room for service personnel.
While minimum clearances are acceptable for safety
reasons, they may not allow adequate air circulation
around the unit for proper operation in the cooling
mode. Whenever possible, it is desirable to allow
additional clearance, especially around the condenser
inlet and discharge openings. DO NOT install the unit
in a location that will permit discharged air from the
condenser to recirculate to the condenser inlet.
TABLE 2
MINIMUM INSTALLATION CLEARANCES
)slairetamelbitsubmocmorf(tcuDteltuOteef3tsrifhcni1
)slairetamelbitsubmocmorf(lanimreTtneV
* sehcni71
teltuOresnednoCsehcni02
poT3erugiFeeS
ecivreSrenruBsehcni02
B,AssalCrodooW(esaBelbitsubmoC
)lairetamgnirevocfoorCro
sehcni0
* A3dna3serugiFeeS
FIGURE 7
LOCATION OF VENT TERMINAL IN SHIPPING
MIS-1689
WARNING
Clearances from combustible materials must
be maintained as specified. Failure to
maintain clearances could cause fire resulting
in property damage, injury, or death.
