Bard WG241 - Table 10 WG241 Indoor Blower Performance

Manual 2100-365
Page 37
TABLE 10
WG241 INDOOR BLOWER PERFORMANCE
@ 230 AND 460 VOLTS
Recommended WG241 cooling airflow range at rated 800 CFM @ 0.15 ESP (WC) is 680 - 920 CFM
Factory set on Low Speed for cooling and High for heating.
Voltage adjustment – Reduce airflow by 100 CFM for 208 Volt
Dehumidification coil adjustment – Reduce airflow by 35 CFM for dehumidification coil installed
Top outlet adjustment – Increase airflow by 50 CFM for top outlet models
SG-3, RG-3, non-ducted application adjustment – Reduce airflow by 100 CFM for SG-3 and RG-3 installations
