Instruction, Use and Maintenance Manual
EN-IST-B925-0218
4. VALVE CONNECTIONS/CONNECTORS:
If the valve is fitted with connectors, you may proceed with installation.
Correctly insert the gaskets and tighten the connectors
.
5. WELDING THE VALVE BODY ONTO PIPING:
1. Insert air couplings in the central connector
2. Remove the body from the rest of the valve before proceeding with
welding operations.
CAUTION!
Hand crushing hazard. During operation there is a crushing hazard
caused by the washing pin or the guide pin (when present).
12
