Step 10. Place the cover onto the riser. Using the cover as
a template, pilot drill the screw holes into the riser using an
⅛” drill bit as shown in Fig. 11.
Step 11. Attach the cover using the provided screws and
washers. Hand tighten screws as shown in Fig. 12.
Fig. 10a
Fig. 10b
Fig. 11
