Step 21: START UP PRE-CHECKLIST

Prior to performing an electrical and hydraulic performance check of the complete station, verify all of the following

criteria are met:

! The shut-off and redundant check valve at force main are installed in the lateral discharge and are in the open

position

! Discharge piping has been pressure tested to 150 PSI max without leakage

! Inlet has a minimum of 1/8” per foot drop

! All penetrations through basin and electrical enclosure sealed water-tight

! Proper backﬁ ll and compaction has been done to prevent deﬂ ection or possible failure of equipment

! All cords are secured and clear of pump cutter and level control

! Electrical supply is of proper voltage, phase for the pump

! A properly sized double pole circuit breaker has been installed in the service disconnect panel

! Proper gauge and conductor wire installed from service disconnect to house panel

! All terminal connections are secure

! Circuit breakers in the Alarm Box are turned to the “OFF” position

! Circuit breaker in the service disconnect turned to “ON”

! Pump is properly seated on the discharge opening in the rail

! Level control is installed properly

! Final grade slopes away from the basin to avoid runoff water collection/ basin inﬂ ow

! All construction and shipping debris has been removed from the basin

Step 22: START-UP CHECKLIST

! Water has been added to the basin to a level of approximately 1” above the pump support ﬂ ange

! Valve(s) within the basin and lateral are in the “OPEN” position (Pull on Green Strap in station)

! Record pump and basin nameplate information on the start-up form (Before installing pump)

! All alarm devices are turned to the “ON” position

! Complete START-UP check sheet located in the back of the manual
