Miniature circuit breaker
•
• Band around SP (High, Low, Ok)
• Thermocouple failure
• Inverted thermocouples
• Heater failure
• Fuse failure
• SSR failure
• Supply line missing
• Wrong powers supply connection
• Loop break alarm
•
•
Terminal for rough environmental conditions
fanless, IP65 protection class
• Monitor: LCD/TFT 10” Wide Led; 250 cd/m
• Contrast 500:1
• Resolution 1024x600 (max 1024x768)
• 4 wires resistive touch screen
• Aluminium alloy front panel
• Zinc plated case or Aluzink
• Intel ATOM Z510P 1.1 Ghz processor
• Intel GMA 500 256 MB VGA (shared)
• 2 x USB 2.0
• Double Ethernet connection 10/100/1000 Mbit RJ45
• RAM: SODIMM DDR2 da 2GB
• 4 GB industrial compact flash
• Windows Xp embedded
• Optional Wi LAN
•
4 Working details
The apparatus is designed to regulate in the best manner the power supplied in each zone
so that the temperature reaches and maintains in time the value set in the active Set point.
When turning on the temperature controller it is possible to choose to activate the drying
phase and auto-tuning. Terminated the drying phase on every zone a ramp is activated
increasing the temperature while limiting the maximum power supplied (soft start). At the end
of the soft start every zone continues heating without any limits regarding the power supplied.
When each zone reaches a temperature equal to 75% of the active set point, the auto-tuning
procedure begins. Only when the zones terminate this last phase, normal regulation begins,
until reaching and maintaining the active set point.
There are some features that make TH-M6 24-48 zones system different from a simple
apparatus for temperature control. The main ones are:
• possibility to manage a non limited number of working recipes
