10.1.2 Connection
Diagram
Pos. Description
1 Host PC with Bluetooth
2 Mobile device with Bluetooth for non-hazardous areas (e.g. Agile tablet PC or other)
3
Mobile device with Bluetooth for potentially explosive atmospheres (e.g. Agile X or Agile X IS
tablet PC, or other)
4 BCS 3678
ex
hand-held scanner
