Bartec BCS36 8ex Series User Manual

6 Configuration
Handscanner
BCS 3600
ex
series
64 / 106
Subject to technical modifications
Revision A / 04/2019
6.5.7 Creating Pairing Barcodes with Zebra 123 Scan Utility
Start the Zebra 123Scan Tool application.
Select the following menu items in the start screen.
In the field "Pairing value": enter the MAC address of the Bluetooth module.
"Select "generate bar code
Then scan the two barcodes one after the other for pairing.
6.6 Threshold values for battery level for Bluetooth hand-held scanners
The thresholds for displaying the battery status are defined as follows:
Status
Factory settings
BCS 3678
ex
-NI
BCS 3678
ex
-IS
High – green LED
50 %
Middle – orange LED
20 %
Low – red LED
10 %
Overall condition Low 60 %
Table 53 Thresholds
However, you can change the threshold values individually within the value range from 0 to 99 %.

Bartec BCS36 8ex Series Specifications

General

Brand	Bartec
Model	BCS36 8ex Series
Category	Barcode Reader
Language	English
