Table L: Selecting the appropriate monitoring equipment:
Base your selection on the number and type of trace heating circuits to be installed, the type of continuity monitoring you need, and the area
classification:
TABLE L: Monitoring Equipment Selection Recommendations
Heating circuit type
Application
Monitoring options
Suitable BARTEC monitoring product
Quantity required
Self-regulating heating circuits on pipes
Freeze protection
High profile end seal or
signal light for indication
ELS-200
ELL-200
1 per circuit
Self-regulating heating circuits on pipes
Temperature maintenance or
tight temperature control
High profile end seal
ELS-200
1 per circuit
→ Example
 The application is temperature maintenance (25 °C) of a pipe in a hazardous area.
 The maintenance team wants to be able to quickly locate the end seal.
appropriate monitoring equipment = ELS-200
Step 13: Finalize the required Materials List (BOM):
Accessories including the glass tape for attachment and pipe straps for the components and electrical traced warning labels
→ Example
 Heating cable catalog no. (see Step 1-5 beginning on page 6) and required length (see Step 9 on page 16) =
 Temperature control device including power connection enclosure (see Step 12 on page 18)
 High profile end seal for ease of maintenance (see Step 12 on page 18) =
 Accessories (see section Accessories on page 27-30):
Glass cloth tape (see selection table in section Accessories)
Pipe straps (see selection table in section Accessories)
Electrically traced warning labels
10PSB2-CT
PBTW-200-E
ELS-200
GT-164
PC-1
HTWL-EN
64 m
1 pc.
1 pc.
1 rolls
4 pcs.
16 pcs.
