21-1S00-7D0001/-
05/2023-EHT-466853
Notice Technical data subject to change without notice.
No claims for damage arising from alternations, errors or misprints shall be allowed.
Trace heater Installation Enclosure as Power Box kit
Junction box with mounting stand
Max. workpiece
temperature mounting
stand
2
Max. trace heater entries
Spring clamp Ex e; 2x3
lines, 1x3 PE
Spring clamp Ex e; 3x3
lines, 2x3 PE
Spring clamp Ex e; 4x3 lines,
2x3 PE
Spring clamp Ex e; 2 x lines,
2 x neutral, 2 x PE
Maximum circuit breaker
size
4
Ambient temperature range
Min. installation temperature
Power supply cable
Service temperature at con-
ductor
5
MSB:
70 °C @ Ta max 40 °C
80 °C @ Ta max 55 °C
PSB:
70 °C @ Ta max 40 °C
85 °C @ Ta max 55 °C
80 °C @ Ta max 55 °C (@ 24 A max.)
Connection Technology (CAK)
Maximum withstand tem-
perature / max. service tem-
perature end seal
Min. installation tempera-
ture
Connected
trace
heater type
Trace
heater
rated
power out-
put [W/m]
Limitation of operating current (stady state) of trace
heating circuit at T
amb max
[A]
Max. surface temperature
“T
L
” [°C]
Maximum workpice temperature depending on the type of trace heater, used
Protecting of all components of the branch circuit against over-current; choice depending on design parameters
For supply cable type selection, the permissible operating temperature at the conductor is to be observed with respect to the maximum ambient temperatue of the power box.
