Checklist customized entry port
For customized power entry port or capilliary tube entry, the following data are mandatory for type selection of:
Component:
Power cable
gland
Power entry blind
plug
Breather device;
Drain device
Capilliary tube
cable gland
Identification:
Manufacturer:
Type:
______________
______________
______________
______________
______________
______________
______________
______________
______________
______________
______________
______________
Identification:
Manufacturer:
Type:
______________
______________
______________
______________
______________
______________
______________
______________
______________
______________
______________
______________
Standards
to comply:
IEC 60079-0:2017; IEC 60079-7:2017;
IEC 60079-31:2013
IEC EN 60079-0:2018; EN 60079-7:2015 +
A1:2018;
EN 60079-31:2014
yes
yes
yes
yes
Type of protection:
Ex eb, Ex tb
yes
yes
yes
yes
Ambient tempera-
ture range:
PSB: -55 °C to +75 °C
MSB: -55 °C to +70 °C
Temperature ranges are also valid for earth lugs
with cord.
___°C to ___°C
___°C to ___°C
yes
___°C to ___°C
___°C to ___°C
yes
___°C to ___°C
___°C to ___°C
yes
___°C to ___°C
___°C to ___°C
yes
Degree of ingress
protection:
IP66 in accordance with IEC 60529
and IEC 60079-0
yes
yes
yes
yes
Grade of mechani-
cal risk:
High (7J)
yes
yes
yes
yes
Material
metal or plastic;
For nuts and gland, mounted together, the mate-
rial shall be equal for keeping the Grade of me-
chanical risk at High (7J).
yes
kind of material:
______________
yes
kind of material:
______________
yes
kind of material:
______________
yes
kind of material:
______________
Thread size:
M20x1.5; M25x1.5; M32x1.5
also suitable for nuts
M ___x1.5
yes
M ___x1.5
yes
M ___x1.5
yes
M12x1 only
yes
For installation of selected components, the manufacturer’s installation manual must be observed. Thus above mentioned advices may differ.
It must be added to the junction box documentation.
It is not allowed to add or manipulate drillings and threads at the BARTEC junction box.
For selecting type of Power supply cable, see chapter Technical Data.
Remarks:
________________________________________________________________________________________________________________________________
____________________________________
City/Date
_____________________________________
Engineer
Name / Signature
_____________________________________
Customer
Name / Signature
NOTICE
Claims under warranty will not be considered if the check list is not filled in completely.
