INSTALLING THE CHARGING STATION (400-157)
6 3/8”
(162 mm)
13/16”
(21 mm)
4 3/8”
(111 mm)
2 13/16”
(72 mm)
The above schematic shows the location of all of the mounting holes.
The wall mounted charging station should be fastened to the wall using 1/4” screws
with the appropriate wall anchors (will vary depending on your facility’s wall structure).
