Placing the Battery Pack on the Lift
To place the battery on the electronics pack, hold the battery pack by the top handle and
place your other hand on the back of the pack. Place the battery on top of the electronics
pack and push the battery toward the mounting plate until the metal tab on the top of the
battery pack locks into place.
Removing the Battery Pack from the Lift
To remove the battery pack, grab the battery pack by top and pull back the metal tab,
releasing it from the mounting plate (figure 1). Once this tab is released, pull the battery
pack away from the lift (figure 2).
Figure 1
Figure 2
PLACING AND REMOVING THE BATTERY PACK - BARIATRIC
28
