Notes:
Push the buttons firmly, but not too hard, to avoid damaging the circuit
boards. Also, to avoid entering incorrect data, do not push the buttons
too fast.
When the instrument is used for pump control, please avoid to directly
connect the relays to pump power supply circuit.
When there is RS485 serial communication, the relay No.6 is invalid.
The remote control can also be used to configure the parameters. There
are four keys SET、MOV、INC、SEL. MOV、INC and SEL three keys
have same functions as they are in the host panel. SET key is used to
enter or exit the programming mode.
5. Calibration
The instrument should be calibrate indoor before installation to ensure the normal
performance.
