15
UPPER/LOWER BASE PARTS LISTING
2 E11973 Hose Clamp, 1/2" OD Hose, Snap Grip, Plastic 3
4 EP50154 Vacuum Motor 120 VAC 800 Watt 1
5 EP50155
Tubing, 1/4" ID x 7/16" OD x 140mm L, Braid Reinforced , PVC 1
6 EP50156
Tubing, 1/4" ID x 7/16" OD x 216mm L, Braid Reinforced , PVC
1
7 EP50157
Tubing, 1/4" ID x 7/16" OD 228mm L, Braid Reinforced , PVC
1
8 EP50158
Tubing, 1/4" ID x 7/16" OD 312 mm L, Braid Reinforced , PVC
1
9 EP50159
Tubing, 1/4" ID x 7/16" OD 133mm L, Braid Reinforced , PVC
1
10 E81068 Washer, Fender, 1/4", Zinc 2
11 E81125 Wheel, 4" OD, 1/2" ID, Non Marking 2
12 E82761 Washer, Flat, M6 x 12 x 1.6, Zinc 9
13 E83143 Axle Cap 0.5" 2
14 E83145 Nylon Washer 2
15 E83269 Washer, Spring, 1/2" ID 2
16 E83550 Nut, Hex, M6, Nylon Lock, Zinc 3
17 E85553 Pump 1
18 E88588 Fitting, Elbow, 1/8" MNPT x 1/4" Barb, Brass 2
19 E88592 Gasket, Upper Vacuum 1
20 E88595 1/4" Inline Filter 130 micron 1
21 E88597 Lower Base 1
22 E88617 Thumb Nut 2
23 E88621 Watering Tube 1
24 E88624 Wood Floor Brush 1
25 E88625 Right Side Brush Cover Weldment 1
26 E88626 Bearing, Ball, M19 OD x M10 ID x M5 T, Sealed 2
27 E88627 Idler End Hub 1
28 E88628 Snap Ring, External, M10, Zinc 1
29 E88629 Wheel - Front Roller 3
30 E88630 Axle, Transport Wheels 1
31 E88669 Fitting, 1/8" MNPT x 1/4" Barb, Hose Barb, Brass 1
32 E88670
Fitting, Tee, Brass 1/8" MNPT x 1/8" FNPT x 1/8" FNPT 1
33 E88679 Upper Frame 1
34 E88687 Set Screw, M6 x 20, SS 2
35 E88690 Bushing - Bumper Wheel 3
36 E88691 Gasket, Vacuum to Frame 1
37 E88703 Gasket, Vacuum-Tank Seal 2
38 E88715 Screw, 1/4" x 3/4", Plastite Pan Head, Zinc 15
39 E88719 Washer, Flat, M6 x M22 x M2, Zinc 4
40 E88742 Splash Guard 2
41 E88743 Band Clamp 2
42 E88744 Screw, M3 x 6, Button Head, Socket, SS 3
43 E88745 Nut Plate 1
44 E88746
Screw, Machine, M3 x 12, Button Head, Socket, SS
3
45 E88888 Bolt, Hex, M6 x 40, Zinc 3
Item# Part # Description Qty. Item# Part # Description Qty.
