17
HANDLE BASE PARTS LISTING
1 E20123 Washer, Split Lock, M5, Zinc 6
2 E81076 Nut, 3/8"-16, Nylon Lock, Grade 5, Zinc 2
3 E81180 Serial Number Decal 1
4 E82256 Nut, M5 x 7, Nylon Lock, Zinc 6
5 E82761 Washer, Flat, M6 x 12 x 1.6, Zinc 8
6 E83381 Nut, M10, Nylon Lock, Zinc 1
7 E83550 Nut, Hex, M6, Nylon Lock, Zinc 8
8 E83836 Bolt, Hex,t M5 x 16, Zinc 2
9 E83879 Washer, Flat M5 x 11 x 1, Zinc 7
10 E83881 Hex Bolt M5 x 20 Zinc 4
11 E88593 Handle Tower Pivot Shaft Hub 1
12 E88594 Washer, Split Lock, M6 Zinc 16
13 E88596 Handle Tower Weldment 1
14 E88598 Handle Adjust Gear 1
15 E88599 Handle Tower Pivot Shaft 1
16 E88600
Bushing, Flange, 20mm ID, 24mm OD, 28mm Flange, 20mm L, Bronze
1
17 E88601 Washer, M10 x 30 x 2.5, Zinc 1
18 E88602 Handle Pivot Rod 1
19 E88603 Pin, Clevis 3/16 x 0.75, Zinc 1
20 E88605 Male Coupling 1
21 E88606 O-Ring, M16 x 2.00 2
22 E88607 Handle Mounting Plate Weldment 1
23 E88622 Handle Nut Plate 1
24 E88632 Handle Adustment Cam Lock 1
25 E88672 Caster 2" OD, 3/8" - 16", 1" L Post 2
26 E88673 Washer, Fender 3/8" x 1 1/4" Zinc 3
27 E88696
Screw, #8-32 x 0.375 Thread Forming, Pan Head, Phillips, Zinc
1
28 E88701 Bumper 1
29 E88708 Grommet, EPDM 60 Durometer 1
30 E88715 Screw, 1/4" x 3/4", Plastite Pan Head, Zinc 6
31 E88747 Bolt, Hex, M6 x 80, Zinc 8
32 E88751 Screw,1/4"-20 x 5" Flat Head, Zinc 6
33 E88801 Cotter Pin, 1/16" Hairpin 1
34 E88812 Male Coupling Shim 1/16" 1
35 E88813 Male Coupling Shim 1/8" 1
36 E88889 Relay 120 VAC 1.5 HP 1
Item# Part # Description Qty. Item# Part # Description Qty.
