Configuring the Camera
BASLER A202
k 4-31
DRAFT
4.2.8 Bitrate Command
Purpose: To set the bitrate of the serial communications link. The bitrate is changed immediately after
the successful receipt of this command. (The default bitrate is 9600.)
Type: This is a write only command.
Write Command: Cmd-ID R/W-Flag Data Length Data
0x44 0 4 4 Bytes
Response: None
Data Format: Byte 1 An ID that specifies the bitrate (see table below).
Byte 2 undefined - always write 0x00
Byte 3 undefined - always write 0x00
Byte 4 undefined - always write 0x00
ID Bitrate
0x12 4800
0x13 9600
0x14 14400
0x15 19200
0x17 38400
0x19 57600
0x1A 76800
0x1B 115200
L
When changing the bitrate for serial communication, use the following procedure:
1. Issue the write command with the new bitrate.
2. Wait one second.
3. Change the bitrate on the serial port that the camera is using:
a) If you are using a Camera Link frame grabber, change the bit rate on the
frame grabber’s RS-644 serial port.
b) If you are using the camera with a k-BIC, change the bit rate on your PC’s
RS-232 serial port.
4. Resume communication.
Note: At a camera reset or a power off/on, the camera will return to the 9600 bps
default setting.
The RS-644 serial port on some Camera Link frame grabbers will only support a
bitrate of 9600. If you are using a Camera Link frame grabber, check the grabber’s
documentation before attempting to change the bitrate.
