Basler A202k User's Manual Supplement

Supplement
10 Basler A202k High Gain
DRAFT
4.2 Digital Shift Binary Command
On high gain cameras, a “shift three times” setting has been added to the data formats for the
digital shift binary command. The additional setting is shown in the table below.
Purpose: To enable or disable digital shift.
Type: This is a read or write command.
Read Command: Cmd-ID R/W-Flag Data Length Data
0xA5 1 1 -
Response: Cmd-ID R/W-Flag Data Length Data
0xA5 0 1 1 Byte
Write Command: Cmd-ID R/W-Flag Data Length Data
0xA5 0 1 1 Byte
Response: None
Data Format: Byte 1 An ID that specifies the digital shift status
(see the table below).
ID Digital Shift
0x00 No digital shift
0x01 Digital shift once (multiples output 2X)
0x02 Digital shift twice (multiples output 4X)
0x03 Digital shift thee times (multiples output 8X)
