6.2 Timer 2 Binary Command
Purpose: To set Timer 2 or to read the current Timer 2 setting. Timer 2 is used when the camera is
operating in free-run mode. See Section 3.2 for details.
Type: This is a read or write command.
Read Command: Cmd-ID R/W-Flag Data Length Data
0xA7 1 3 -
Response: Cmd-ID R/W-Flag Data Length Data
0xA7 0 3 3 Bytes
Write Command: Cmd-ID R/W-Flag Data Length Data
0xA7 0 3 3 Bytes
Response: None
Data Format: Byte 1 Low byte of the Timer 2 setting
Byte 2 Mid byte of the Timer 2 setting
Byte 3 High byte of the Timer 2 setting
Data Range: Timer 2 settings can range from 42 (0x00002a) to 16777215 (0xFFFFFF).
The Timer 2 setting represents a multiple of 0.88889 µs. For example, if the
Timer 2 setting is 100, then the value of Timer 2 would be:
100 x 0.88889 µs = 88.889 µs
