5-2 BE1-50/51B-218/-228 Testing 9252000995 Rev G
BE1-50/51B
65 3 1
TIMEINST
2
CURRENT
SOURCE
INPUT
STOP
TIMER
START
AMPS
TEST SET
D1148-25
12-09-99
Figure 5-1. Pickup and Timing Test Setup
BE1-50/51B
65
CURRENT
SOURCE
INPUT
STOP
TIMER
START
AMPS
TEST SET
1.0A
CURRENT
LIMITER
TARGET CURRENT
23
INST
1
TIME
D1148-24
12-09-99
Figure 5-2. Target Operational Test Setup
