4-12 BE1-50 Installation 9171000990 Rev E
CONNECTIONS
Be sure to check the model and style number of a relay before connecting and energizing the relay.
Incorrect wiring may result in damage to the relay. Except where noted, connections should be made with
wire no smaller than 14 AWG.
Typical sensing input connections are shown in Figures 4-11 through 4-14. Typical output connections
are shown in Figures 4-15 and 4-16. Internal wiring diagrams are shown in Figures 4-17 through 4-19.
Figure 4-11. Single-Phase Sensing Input Connections
