Basler dart User Manual

Quick Installation Guide for Basler dart Cameras AW00130404000
8 Basler dart
NOTICE
Incorrect cleaning can damage camera components.
 Before starting the cleaning procedure, disconnect the camera from camera power by
unplugging the plugs from the USB 3.0 connector.
 After the cleaning procedure, make sure the cleaning material has evaporated before you
reconnect the plugs.
 For dart bare board, dart S-mount and dart CS-mount mono variants, i.e. for dart cameras
where the sensor is accessible:
 Avoid cleaning the surface of the camera’s sensor.
If you must clean it, use a soft, lint-free cloth dampened with a small quantity isopropanol.
 Use a cloth that will not generate static charge during cleaning (cotton is a good choice).
Electrostatic discharge might damage the sensor.
 For dart CS-mount color variants:
 Try not to touch the IR cut filter and do not clean the IR cut filter mechanically. The glass
of the IR cut filter can break if you apply too much pressure.
 Use clean, oil-free compressed air to clean the IR cut filter. Be careful not to apply too
much air pressure.
 Do not use solvents or thinners to clean the board or the camera front or both; they can
damage the surface.
NOTICE
An incorrect plug can damage the connectors.
 The plug on the cable that you attach to the camera’s I/O connector must have 6 male pins
and must be terminated with a 1.27 mm pitch dual row plug.
 The plug on the cable that you attach to the camera’s USB 3.0 Micro-B connector must be
designed for use with the USB 3.0 Micro-B connector.
Trying to use any other type of plug can destroy the connectors.

Basler dart Specifications

General

Sensor Type	CMOS
Interface	USB 3.0
Mount	CS-mount
Shutter Type	Global shutter, Rolling shutter
Operating Temperature	0°C - 50°C
Dimensions	29 mm x 29 mm x 29 mm
Resolution	Up to 5 MP
Optical Size	1/1.8", 1/2.5", 1/3.2"
