7-12 9469300994
Specifications DGC-2020HD
Type Tests
Shock
Withstands 15 G in 3 perpendicular planes.
DGC-2020HD with DIN Rail mount (style xRxxxxxxx) and Rear Panel mount (style xPxxxxxxx)
Withstands 10 G, 3 times, in 3 perpendicular planes.
Vibration
Tested for 8 hours in three perpendicular planes.
3 to 25 Hz ......................................... at 0.063 in (1.6 mm) peak amplitude
25 to 2,000 Hz .................................. at 5 G
DGC-2020HD with DIN Rail mount (style xRxxxxxxx) and Rear Panel mount (style xPxxxxxxx)
Tested for 2 hours and 40 minutes in three perpendicular planes.
10 to 150 Hz at 2.5 G
HALT (Highly Accelerated Life Testing)
HALT is used by Basler Electric to prove that our products will provide the user with many years of
reliable service. HALT subjects the device to extremes in temperature, shock, and vibration to simulate
years of operation, but in a much shorter period span. HALT allows Basler Electric to evaluate all possible
design elements that will add to the life of this device. As an example of some of the extreme testing
conditions, the DGC-2020HD was subjected to temperature tests (tested over a temperature range of
–85°C to +120°C), vibration tests (of 5 to 40 G at +30°C), and temperature/vibration tests (tested at 40 G
over a temperature range of –85°C to +120°C). Combined temperature and vibration testing at these
extremes proves that the DGC-2020HD is expected to provide long-term operation in a rugged
environment. Note that the vibration and temperature extremes listed in this paragraph are specific to
HALT and do not reflect recommended operation levels.
Ignition System
Tested in close proximity to an unshielded, unsuppressed Altronic DISN 800 Spark Ignition System.
Environment
Operating Temperature .................... –40 to +158°F (–40 to +70°C)∗
Storage Temperature ....................... –40 to +185°F (–40 to +85°C)
Salt Fog ............................................ IEC 60068
Ingress Protection ............................ IEC IP56 for front panel
Humidity ........................................... IEC 68-2-78
∗ The operating temperature of DGC-2020HD units with the color touch screen display option
(style xTxxxxxxx) is derated to –4 to +158°F (–20 to +70°C).
Agency, Standards, and Directives
UL Approval
The DGC-2020HD is a Recognized Component applicable to the Canadian and US safety standards and
requirements by UL. The product is covered under UL File (E97035 FTPM2/FTPM8).
Standards used for evaluation:
• UL 6200:2019
• CSA C22.2 No. 14
