Battery Backup Power BBP-AR-2000-PSW-ONL User Manual

41
Bypass Supply
＜
105
％
continuous
106-120％ for 250 seconds shuts down
121-130％ for 125 seconds shuts down
131-135％ for 50 seconds shuts down
136-145％ for 20 seconds shuts down
146-148％ for 5 seconds shuts down
149-157％ for 2 seconds shuts down
158-176％ for 1 seconds shuts down
177-187％ for 0.32 seconds shuts down
＞188％ for 0.16 seconds shuts down.
Buzzer continuously alarms.
Efficiency
( Full Linear
Load )
Line mode
(Rating 120Vac)
>90% >91% >91% >92%
Battery mode
(12Vdc/pcs)
>87% >87% >87% >87%
ECO mode
(Rating 120Vac)
>97%
Battery
Number of batteries 2 3 4 6
Battery type 12 V/9Ah Sealed, non-spillage, maintenance-free, lead acid
Rated Battery Voltage 24 VDC 36 VDC 48 VDC 72 VDC
Backup time
(Linear Load)
50%
Load
>9min >9min >9min >9min
70%
Load
>5min 30sec >5min 30sec >5min 30sec >5min 30sec
100%
Load
>3 min >3 min >3 min >3min
Charger
Charge
Current (Max.)
Standard
1.8 A 1.8 A 1.6A 1.4 A
Supplementary
Charger
(Max.)
Optional
3.1A 3.1A 3.1A 3.1A
Recharge time
(to 90%)
4hr 4hr 4hr 4hr
Floating Mode Charging
Voltage
27.3Vdc±1％ 40.95 dc±1％
54.6Vdc±1％
81.9Vdc±1％
Bulk Mode Charging
Voltage
28.2Vdc±1％ 42.3Vdc±1％ 56.4Vdc±1％ 84.6Vdc±1％
DC leakage current ≤ 30 µA with no AC applied and the unit in the off position
Transfer
time
AC to DC 0 ms
Inverter to Bypass 2.5 ms (Typical) 0 ms (Typical)
DC start
startup in battery mode
during a power failure
Yes
Self
Diagnostics
Upon Power-on, Front Panel Setting & Software Control, 24
hours routine check
Programma
ble outlet
Programmable relay support 2 outlets
Front Panel
LCD (Standard)
LED (Optional)
Normal, Battery, Bypass, Self-Test, Battery Weak & Bad,
Site Wiring Fault , Fault, Overload, and Load/Battery Level
Programmable Outlet1/ Programmable Outlet2
4 Button (Optional) ON / OFF / Select / Silence
6 Button (Standard) ON(Silence) / OFF / Enter / Function / UP / Down
