Battery Backup Power BBP-AR-2000-PSW-ONL User Manual

40
9. Specifications Convertible Type (Tower)
MODEL ITEM
BBP-AR-1000-
PSW-ONL
BBP-AR-1500-
PSW-ONL
BBP-AR-2000-
PSW-ONL
BBP-AR-3000-
PSW-ONL
CAPACITY
VA 1000 VA 1500VA 2000 VA 3000 VA
W 900W 1350W 1800W 2700W
INPUT
Voltage Rating
55/75/90-150 VAC
(Based on load percentage 0-60% / 0-75% / 0-100%)
Frequency Rating
44-66 Hz
50Hz fin< 44Hz or fin > 56Hz
60Hz fin< 54Hz or fin > 66Hz
Phase
Single phase with ground
Power Factor
≧ 0.99 at full linear load
Current harmonic
distortion (THDi)
<7% at full load and nominal voltage
Generator Input
Supported
Input Connection NEMA 5-15P NEMA 5-15P NEMA 5-20P NEMA L5-30P
Output
Voltage * 120 V, adjustable to 100/110/115/120
Voltage Regulation
Static：within ±1% until low-battery warning
Frequency
(Synchronized Range)
3 Hz or 1 Hz (selectable)
Frequency (Battery
Mode)
50/60 Hz ±0.2% unless synchronized to line
Current Crest Ratio 3:1
Voltage Harmonic
Distortion(THDv)
< 3% at full linear load
< 6% at full non-linear load
Measure Load
tolerance
±2%
Measure voltage
tolerance
±1%
Dynamic stability
≦60ms/5% @ 10% to 90% Load
Output Waveform Pure sine wave
Outlets
(6)
NEMA 5-15R
(6)
NEMA 5-15R
(6)
NEMA 5-20R
(6+1)
6*NEMA 5-20R
1*NEMAL5-30R
AC Inverter Supply
＜
105
％
continuous
106-120％ for 30 seconds transfer to bypass
121-150％ for 10 seconds transfer to bypass
＞150％ Immediately transfer to bypass.
Buzzer continuously alarms.
Battery Supply
＜
105
％
continuous
106-120％ for 30 seconds shuts down
121-150％ for 10 seconds shuts down
＞150％ Immediately shuts down.
Buzzer continuously alarms.
