Rev. A-061015 Page 11 P/N VDC1215C-MNL
BatteryMINDer
®
Model 1215C
TABLE 3: VOLTAGE TABLE
MV: Minimum Voltage of a battery the unit will accept.
CV: Charge Voltage to move from Constant Current stage into
Maintenance stage.
M: Voltage during the Maintenance stage.
Model Battery Types MV CV M
1215C 12V Lead-Acid 3.0V 14.4V 13.4V
All readings must be taken at 77°F (25°C)
Attaching BatteryMINDer 1215C
NOTE: When not connected
to an electrical source and
while attached to the bracket
under the hood and to your
car battery (fig. 1, 2, 3 & 4),
the BatteryMINDer does not
provide power to nor draw
power from your vehicle.
1
5
43
2
