FEATURES
1
LED Indicators (see expanded views on page 8)
2
A.C. Input plug
3
ATS-1 Ambient Temperature Sensor
4
Temperature Sensor input connector
5
Output cord with quick connect plug (tethered cap not shown)
6 Fully Insulated Battery Clip cord set (Aircraft-Grade) with 15A
replaceable fuse assembly
7
Permanent brackets + screws (removable - optional)
8
Ring terminal assembly with 15A replaceable fuse
7
6
8
3
5
2
1
4
7
