MVT26
October 2003 Section 3 Page 37
Item Qty Part No. Description Notes
◊ 1 060107 Piston and Cylinder Assembly
1 1 67057 Cylinder Guide 60mm Dia
2 1 N3731 O-ring
3 1 67061 Cylinder 32mm Dia
4 1 N7063 O-ring
Figure 3.1-22 3rd Stage Piston and Cylinder
8
1
1
10
9
11
13
14
12
2
1
4
3
7
6
5
