USER INSTRUCTIONS
REMOVING THE OVEN DOOR
To facilitate cleaning inside the oven, the door can be removed as
follows:
1) With the door in the fully open position, swivel the catch on each
lower arm and clip over the hook on each upper arm (see Fig.1).
2) Hold the door on each side, then lift to unhook the hinge
mechanism and pull outwards to release from the oven.
3) To refit, hold the door in the fully open position and slide the
hinge arms into the oven recesses until the arms lock in position.
On models with hinge mechanisms as per Fig.1, release the hinge
clips and close the door fully to complete the refitting.
WARNING
• Take care not to dislodge the hinge lock system when
removing the door as the hinge mechanism has a strong
spring system!
• Do not immerse the door in water at any time.
Fig.1
16
