Replacing the oven bulb
IMPORTANT: The oven must be disconnected from
your mains supply before you attempt to either
remove or replace the oven bulb.
o Draw out the side guide rails in order to provide access to the
bulb.
o Remove the glass protection cap (C)
from the bulb socket by lifting it with a
screwdriver placed between the cap and
the oven wall.
o Replace the bulb (B) with a 15
W/300°C, screw type pygmy.
o Do not use any other type of bulb.
o Screw the lamp cover back into its original position.
Removing the oven door for cleaning
o The oven door can be removed to give easier access to the oven
when cleaning.
o Open the oven door and insert a rivet or nail (R) in the hole (F)
of the hinge (see image below).
o Partially close the door, forcing it
upwards at the same time to free
the stop tooth and hinge sector.
o Once the hinge is free, pull the door
forwards tilting it slightly upwards
to free the sector.
o To reassemble, proceed in the reverse order, playing attention to
the correct position of the sectors.
24
