Baumatic BDW71S - Filter Assembly

The filter prev ent s lar ger remn ant s of food or ot her objects from get ting i nsi de th e pu m.
The residues may block the filter, in this case they must be removed.
The fi lter syst em c onsists of a coar se f ilte r, a flat ( Main f ilte r)
A n d a mi c rofilter( F i ne fi lter) .
Food and soil particles trapped in this filter are pulverizedby a
specia l jet on t he l owe r spray a rm a nd w ashed d own t o d rain.
Larger i tems, suc h as pie ces o f bo ne s or glas s, t ha t c oul d bl o ck
the drain are trapped in the coarse filter. To remove the items
caugh t by t he filter, gen tly s queeze the tap o n th e to p of t his
filter and lift out.
This filter holds soil and food residues in the sump areaand
prevents it from being redeposit on the dishes during wash cycle.
Main filter
1
Coarse filter
2
Fine filter
3
2
3
1
Filter assembly
The filter efficiently
For b est p erfo rmance and res ults, the f ilte r mu st b e cleane d re gularly. t his r eason, it i s a goo d ide a t o
r emo ve t he la rger foo d pa rticl es tr app ed in the f ilte r aft er e ach was h cy cle b y rin sing t he s em icirc ular filte r an d
cup u nder r unnin g wa ter. To r emove th e fil ter d evice, p ull t he c up handle in t he u pward d irection.
re mo ves f ood par ticles fro m th e wa sh w ater, all owing it to be recycle d du ring the cycle.
For
T h e di sh was her mus t ne ver be u sed without the f ilt er s.
Impro per repl ace ment of the f ilter may red uce the perf orm anc e lev el o f t he applian ce
and dama ge dishes and utensils.
St ep 1 Turn t he filter i n ant i-clo ckwis e d irection,：
St ep 2 l ift the filter assy up：
When following this procedure from step1 to step 2, the filter system will be removed;
when following it from Step 2 to Step 1, the filter system will be installed.
1
2
