21
o You must make sure that there is a 5mm gap below the
underneath of the worktop at the front edge of the hob.
Unpacking the appliance
When unpacking the appliance please check that the following items
are contained within the packaging:-
1 Baumatic hob
1 Ceramic hob scraper
1 Installation and instruction manual
1 Baumatic guarantee card
4 Fixing brackets
4 Fixing screws
Installing the appliance
o Cut a hole in the worktop that corresponds with the drawing
shown above.
o If the hob is being installed without an oven below it, a
separator panel must be placed between the bottom of the hob
and the housing below it, at a minimum distance of 10 mm.
o If the hob is being installed with an oven below it, place a
separator panel at a minimum distance of 15 mm and follow the
oven manufacturer’s instructions, ensuring that sufficient
aeration is provided.
