Baumer HÜBNER EExME 12 - Schritt 4; Schritt 5 - Option: Abdeckhaube; Step 4; Step 5 - Option: Cover

MB052T1 - 11080038
Baumer_EEXME12-T1_II_DE-EN (19A1)
12
Montage / Mounting 5
5.4 Schritt 4 5.4 Step 4
5.5 Schritt 5 - Option: Abdeckhaube 5.5 Step 5 - Option: Cover
Zul. Anzugsmoment:
Max. tightening torque:
M
t
= 2...3 Nm
8 9
* *
13a 13b
* *
* Siehe Seite 7 oder 8
See page 7 or 8
36 mm (øA = ø20 mm)
46 mm (øA = ø30 mm)
50 mm (øA = ø40 + ø42 mm)
45 mm
3 mm
øA
