Baumer KTD 3- A4LY9 Series User Manual

Baumer_KTD3A4-KTD3B10-KTD3-Kombinationen_OI_DE-EN_1606.indd  11
InstallationandOperatingInstructions
TachoGeneratorsandProductCombinations(1-part)
KTD 3-... A 4 L Y 9; KTD 3-... A 4 L Y11; KTD 3-… B10;
KTD 3-... + ITD 2... B10, ITD 4… + KTD 3-… B10 …
1. Generalremarks
• For reasons of clarity the operating instruction is rather general. Not all the details
for the application of tachogenerators can be explained comprehensively.
• All instructions given in this manual are generally applicable and relate to the
Baumer tachogenerator series: KTD 3-... A 4 L Y 9; KTD 3-... A 4 L Y11; KTD 3-…
B10; KTD 3-... + ITD 2... B10, ITD 4… + KTD 3-… B10 …
• The tachogenerator comes with device type labels providing most important techni-
calspecications.
2. Qualiedstaff,relevantoperatorstobeaddressed
• Installationandoperationofthetachogeneratorbyqualiedpersonnelonlyandin
compliance with the relevant data sheet.
• Qualiedstaffinthesenseofpresentinstructionsisauthorizedforinstallation,
earthing and marking of devices, systems and circuits compliant to the relevant
safety standards.
3. Appropriateuse
• The tachogenerator is an electromechanical measuring instrument for
voltage output in relation to speed.
• The device must only be deployed as described in the present instructions
andmustnotbeoperatedbeyondthelimitsspeciedinrelatedtechnical
documentation.
• Any other use is considered not appropriate.
• Proper and safe operation of the product is only ensured by appropriate
transport, storage, installation and mounting as well as careful operation
and diligent maintenance.
