KTD 3-... B10
Type
KTD 3-1 B10
KTD 3-2 B10
KTD 3-3 B10
KTD 3-4 B10
KTD 3-6 B10
a
72
72
72
82
82
VDC
10
20
30
40
60
A
plate spring
DIN 6888 - 4x6.5
or 2x3.7
ø0.02 A
ø0.05 A
d =ø7 or ø11 mm
Please specify the desired
bore diameter in your order.
ø85g6
ø114-0.1
45°
ø100
60°
ø6.6
30
32.5
15
a
37
d h6
6x60°(=360°)
015- 7
Pg 7
ground terminal M4
KTD 3-... + ITD 2... B10
Type
KTD 3-1 + ITD 2... B10
KTD 3-2 + ITD 2... B10
KTD 3-3 + ITD 2... B10
KTD 3-4 + ITD 2... B10
KTD 3-6 + ITD 2... B10
a
131.5
131.5
131.5
141.5
141.5
VDC
10
20
30
40
60
A
ø0.05
ground terminal M4
ø0.02 A
A
option:
cable,
axial,
...m
KA...
Pg 7
plate spring
DIN 6888 - 4x6.5
cable,
radial,
...m
KR...
ø114-0.1a
ø85g6
ø100
15
30
ø11h6
73
32.5
60°
6x ø6.6
70
027-10
