Example 2: Write parameter (precision speed = 0.50; switch off point = 0.01)
SOH Adr Cmd reserved Precision speed =0.50 Switchoff point =0.01 EOT CRC
Transmission
01h 20h 68h
30h 30h 30h 30h 30h 30h 35h 30h 30h 30h 30h 31h
04h E0h
00
SOH Adr Cmd reserved Precision speed =0.50 Switchoff point =0.01 EOT CRC
Response
01h 20h 68h
30h 30h 30h 30h 30h 30h 35h 30h 30h 30h 30h 31h
04h E0h
4.3.7. Read / write measuring unit „i“ (69h)
The command is utilized to read or write the measuring unit in mm or inches.
Data = 0 (30h) = mm
Data = 1 (31h) = inch
Example 1: Read parameter (setting = mm)
SOH Adr Cmd EOT CRC
Transmission
01h 20h 69h 04h 5E
SOH Adr Cmd Data EOT CRC
Response
01h 20h 69h
30h
04h D0h
Example 2: Change measuring unit into inches
SOH Adr Cmd Data EOT CRC
Transmisison
01h 20h 69h
31h
04h D2
SOH Adr Cmd Data EOT CRC
Response
01h 20h 69h
31h
04h D2
Example 3: Write measuring unit mm in all SPAs by broadcast command (identifier=99)
SOH Adr Cmd Data EOT CRC
Transmission
01h 83h 69h
30h
04h CDh
Response not confirmed
Important: Parameters are programmed in mm and auto-converted by SPA into inches upon displaying the po-
sition values.
4.3.8. Read / write timeout at bus error RS485 „j“ (6Ah)
This command is utilized to read or write the system time: timeout at bus error. Value range is within 00,1 s to
99,9 s. Tolerance: ±7% at minimum time; < 1‰ at maximum time, approx. 1% at 1.
Function: RS485 bus monitoring during motive shaft positioning operations. If there is no interface activity within
the programmed timeout the motor will stop (EMERGENCY OFF) upon occurring a bus error or in case of an
inactive control. A motor restart requires transmitting the profile (command „S“ or „V“) together with the start
signal (command „D“). Setting 0.00 s means function disabled.
Example 1: Read parameter (time= 2.5 s)
SOH Adr Cmd EOT CRC
Transmission
01h 20h 6Ah 04h 58h
SOH Adr Cmd Time =2.5 s EOT CRC
Response
01h 20h 6Ah
30h 32h 35h
04h C5h
Example 2: Write parameter (time = 13.5 s)
SOH Adr Cmd Loop =13.5 s EOT CRC
Transmission
01h 20h 6Ah
31h 33h 35h
04h C9h
SOH Adr Cmd Loop =13.5 s EOT CRC
Response
01h 20h 6Ah
31h 33h 35h
04h C9h
