Assembly Assembly Information
16 BUG 3/2/20 Basic Feed Unit
5.96064.02 Baumüller Nürnberg GmbH
4.2 Assembly Information
WARNING
Lifting incorrectly can result in personal injury or damage to property. The device should only be lifted
by appropriately qualified personnel using the proper equipment.
• Install the units vertically in a switching cabinet. Mount the BUS 3/21/20 servo power units next to
the BUG 3/2/20 basic feed unit and connect the intermediate circuit using the supplied rails.
DANGER
Relatively long connections are not allowed, since there is a risk of destroying the device!
WARNING
It is crucial to comply with the ventilation measures listed below. Ignoring these measures can lead to
the device overheating.
• Ventilation must be in the specified direction from the bottom to the top.
• Ensure that the flow of air is unobstructed.
• There must be a minimum clearance above and below the device of
100 mm
and you must ensure that there is enough cooling air that can circulate freely!
• The temperature of the coolant 50 mm below the devices may be up to 45 °C.
• Do not locate any additional sources of heat above or below the devices.
• You must avoid degrees of contamination 3 and 4 according to provisional standard
EN 50178:1994 Section
5.2.15.2. The devices are suitable for use in enclosed workshops.
(VDE 0558 Part 1a, Sections 5.4.3.2.1 and 5.4.3.2.2).
• The live parts take more than one minute to discharge.
